GIGABYTE GA-B150N Phoenix-WIFI is a Mini-ITX motherboard based on the Intel B150 chipset. It uses the LGA 1151 socket and supports Intel 6th-generation Core, Pentium, and Celeron processors.
This board is aimed at compact desktops and mini-PC builds. Its highlights include USB 3.1 Type-C, M.2 PCIe SSD support, Intel dual-band Wi-Fi + Bluetooth, and an orange LED lighting design inherited from GIGABYTE’s Phoenix series.
Key Features
Platform: Intel B150 chipset, LGA 1151 socket Memory: 2 × DDR4 DIMM, up to 32 GB, DDR4 2133 MHz, dual-channel Expansion: 1 × PCIe 3.0 x16 slot, 1 × M.2 WiFi slot, 1 × M.2 SSD slot on the rear side supporting SATA and PCIe x4/x2/x1 SSDs Storage: 4 × SATA 3.0 ports, 1 × M.2 SSD slot (32 Gb/s) Networking: Intel Gigabit Ethernet with cFos software, Intel 802.11ac dual-band Wi-Fi, Bluetooth 4.2 Audio: Realtek ALC892 8-channel HD audio with isolated audio PCB area and high-quality audio capacitors Video outputs: HDMI and DVI-D for integrated graphics USB: 1 × USB 3.1 Type-C, 1 × USB 3.1 Type-A, 4 × rear USB 3.0, internal USB 3.0 and USB 2.0 headers Other features: DualBIOS, 5-phase power design, orange LED backlight system, AMI UEFI BIOS
ASRock H87E-ITX/ac is a Mini-ITX motherboard based on the Intel H87 chipset. It uses the LGA 1150 socket and supports Intel 4th-generation Core, Xeon, Pentium, and Celeron processors.
Designed for compact desktops, HTPCs, and small home servers, this board stands out for its rich I/O layout, built-in 802.11ac Wi-Fi + Bluetooth, and strong storage expansion for a Mini-ITX design.
Key Features
Platform: Intel H87 chipset, LGA 1150 socket Memory: 2 × DDR3/DDR3L DIMM, up to 16 GB, DDR3 1600/1333/1066 MHz, dual-channel, XMP support Expansion: 1 × PCIe 3.0 x16 slot, 1 × half-size mini PCI-E slot for Wi-Fi/BT module Storage: 6 × SATA III, 1 × eSATA; supports RAID 0/1/5/10 and Intel Rapid Storage Technology Networking: Intel I217V Gigabit Ethernet + 802.11ac dual-band Wi-Fi, Bluetooth 4.0 Audio: Realtek ALC1150 7.1-channel HD audio with optical S/PDIF output Video outputs: HDMI, DisplayPort, DVI-I for integrated graphics USB: 6 × USB 3.0 and 6 × USB 2.0 BIOS & utilities: AMI UEFI BIOS, ASRock A-Tuning, FAN-Tastic Tuning, XFast 555
ASUS ROG Strix B250I Gaming is a Mini-ITX gaming motherboard based on the Intel B250 chipset. It uses the LGA 1151 socket and supports Intel 6th- and 7th-generation Core, Pentium, and Celeron desktop processors.
With its compact 170 × 170 mm layout, the board is designed for small-form-factor gaming PCs. Its most distinctive feature is the double-decker heatsink design, which stacks the M.2 SSD heatsink above the PCH heatsink to improve cooling and save space on the Mini-ITX PCB.
Key Features
Platform: Intel B250 chipset, LGA 1151 socket Memory: 2 × DDR4 DIMM, up to 32 GB, DDR4 2400/2133 MHz, dual-channel, XMP support Expansion: 1 × PCIe 3.0 x16 slot with ASUS SafeSlot Storage: 2 × M.2 slots and 4 × SATA 6Gb/s ports; supports Intel Optane Memory Networking: Intel Gigabit Ethernet with LANGuard, plus 802.11ac Wi-Fi and Bluetooth 4.1 Audio: ROG SupremeFX 8-channel audio with dual headphone amplifiers, Sonic Studio III, and Sonic Radar III Lighting: Aura Sync RGB LEDs and one Aura 4-pin RGB header Video outputs: HDMI and DisplayPort 1.2 for integrated graphics USB: 6 × USB 3.0 and 2 × USB 2.0 ports
The ASUS ROG Maximus VI Impact is a high-end Mini-ITX motherboard designed for compact gaming and overclocking builds. Built on the Intel Z87 chipset with an LGA 1150 socket, it supports 4th-generation Intel Core processors and allows CPU overclocking with K-series chips.
Its most distinctive feature is a vertical power delivery design, which helps deliver stronger and more stable power than typical ITX motherboards. It also includes a dedicated SupremeFX Impact audio daughter card, an mPCIe Combo II expansion module for Wi-Fi, Bluetooth and NGFF SSD support, and an Impact Control mini-panel for quick BIOS access, ROG Connect, MemOK!, and hardware debugging.
Key Specifications Category Details Form Factor Mini-ITX
Socket / Chipset LGA 1150 / Intel Z87
Memory 2 × DDR3 DIMM
Graphics Slot 1 × PCIe 3.0 x16
Storage 4 × SATA 3.0, 1 × E-SATA, 1 × NGFF
USB 6 × USB 3.0 (4 rear + 2 front), 4 × USB 2.0 rear
Video Output HDMI + DisplayPort
Networking mPCIe Combo II for Wi-Fi and Bluetooth
Audio SupremeFX Impact audio daughter card
Special Features Vertical VRM design, Impact Control panel, ROG Connect
Highlights
Compact but powerful: One of the earliest ROG Mini-ITX motherboards, built for high-performance small-form-factor PCs. Strong VRM layout: The vertical power design improves power delivery and thermal management in a small board area. Overclocking-friendly: Z87 chipset support makes it suitable for unlocked K-series CPUs. Enhanced audio: The SupremeFX Impact daughter card provides better sound without consuming much PCB space. Flexible expansion: The mPCIe Combo II module adds wireless connectivity and NGFF SSD support.
The ROG STRIX B660-I GAMING WIFI is a high-performance Mini-ITX gaming motherboard built on the Intel B660 chipset. It uses the LGA 1700 socket and supports Intel 12th, 13th, and 14th Gen Core processors, along with Pentium Gold and Celeron CPUs.
Rear USB 1 × USB 3.2 Gen 2x2 Type-C, 4 × USB 3.2 Gen 1, 3 × USB 2.0
Highlights
Strong power delivery: The 8+1 power stage design helps support multi-core Intel processors in a compact ITX layout. PCIe 5.0 support: Provides a PCIe 5.0 x16 slot for next-generation graphics cards. Fast storage: Two M.2 slots both run in PCIe 4.0 x4 mode, with an M.2 heatsink and Q-Latch tool-less clip. Solid networking: Equipped with Intel Wi-Fi 6 and Intel 2.5Gb Ethernet for stable wired and wireless connections. DIY-friendly features: Includes a pre-mounted I/O shield, Q-LED diagnostic LEDs, and M.2 Q-Latch for easier installation. Smart controls: Supports ASUS AI Cooling, AI Networking, and Two-Way AI Noise Cancelation.
The ASUS Z87I-DELUXE is a Mini-ITX motherboard based on the Intel Z87 Express chipset, designed for compact, high-performance builds using Intel 4th Generation Core processors.
Overview Chipset: Intel Z87 Express Chipset Form factor: Mini-ITX (17 cm × 17 cm) CPU socket: LGA 1150 Supported CPUs: Intel 4th Generation Core i7 / i5 / i3, Pentium, and Celeron processors (22nm)
Memory 2 × DDR3 DIMM slots Dual-channel DDR3 memory Supports up to 16GB Memory speeds up to DDR3 3000 MHz (O.C.), 2933/2800/2666/2600/2500/2400/2200/2133/2000/1866/1600/1333/1066 MHz Supports Intel XMP
Audio & Network Realtek ALC1150 8-channel HD audio codec Intel I217-V Gigabit LAN Wi-Fi 802.11 a/b/g/n/ac (dual-band 2.4/5 GHz) Bluetooth v4.0 / v3.0 + HS
Rear I/O DisplayPort, HDMI, DVI-I 6 × USB 3.0 ports (back panel) 4 × USB 2.0 ports (back panel) RJ-45 LAN port Optical S/PDIF out 6-channel audio jacks 2 × Wi-Fi GO! SMA antenna ports USB BIOS Flashback button Clear CMOS button
Key Features ASUS DIGI+ VRM 12+2 phase digital power design ASUS UEFI BIOS with EZ Mode ASUS Wi-Fi GO! Precision Tweaker 2 for detailed voltage and frequency tuning USB 3.0 Boost Network iControl ASUS 5X Protection MemOK! Fan Xpert 2
The ASUS P8H77-I is a Mini-ITX motherboard based on the Intel H77 chipset, designed for compact builds using Intel LGA 1155 processors.
Overview Chipset: Intel H77 Express Chipset Form factor: Mini-ITX CPU socket: LGA 1155 Supported CPUs: Intel 2nd/3rd Generation Core i7, Core i5, Core i3, Pentium, and Celeron processors (32nm/22nm)
Memory 2 × DDR3 DIMM slots Dual-channel DDR3 memory Supports up to 16GB Memory speeds up to DDR3 2200 MHz (O.C.), 2133/2000/1866/1600/1333/1066 MHz
Expansion 1 × PCI Express 3.0/2.0 ×16 slot PCIe 3.0 bandwidth is available when using 3rd-generation Intel Core processors
Storage 2 × SATA 6Gb/s ports 4 × SATA 3Gb/s ports Supports RAID 0, 1, 5, 10 Supports Intel Rapid Storage Technology and Intel Smart Response Technology
Audio & Network Realtek ALC887 8-channel HD audio codec Realtek RTL8111F Gigabit LAN controller
Rear I/O HDMI, DVI, and VGA video outputs USB 3.0 and USB 2.0 ports RJ-45 LAN port PS/2 port Audio jacks
Key Features ASUS DIGI+ VRM digital power design ASUS UEFI BIOS with EZ Mode MemOK! memory compatibility assistance ASUS Anti-Surge Protection USB 3.0 Boost Network iControl bandwidth management
PDF схемы и технические материалы платы Olimex ESP32-C5-DevKit-Lipo. В архиве 1 PDF; страниц: 1. Файлы: ESP32-C5-DevKit-Lipo_Rev_A. Автор: OLIMEX Ltd. Аппаратные схемы: CERN-OHL-S 2.0; лицензия и уведомления в архиве.
PDF схемы и технические материалы платы Olimex GateMateA1-EVB. В архиве 3 PDF; страниц: 3. Файлы: GateMateA1-EVB_Rev_A, GateMateA1-EVB_Rev_B, GateMateA1-EVB_Rev_C. Автор: OLIMEX Ltd. Аппаратные схемы: CERN-OHL-S 2.0; лицензия и уведомления в архиве.
PDF схемы и технические материалы платы Olimex RT1010Py-DevKit. В архиве 2 PDF; страниц: 2. Файлы: RT1010Py-DevKit_RevB, RT1010Py-DevKit_Rev_B-BOM. Автор: OLIMEX Ltd. Аппаратные схемы: CERN-OHL-S 2.0; лицензия и уведомления в архиве.
PDF схемы и технические материалы платы Olimex ESP32-C5-EVB. В архиве 2 PDF; страниц: 2. Файлы: ESP32-C5-EVB_Rev_A, ESP32-C5-EVB_dimensions. Автор: OLIMEX Ltd. Аппаратные схемы: CERN-OHL-S 2.0; лицензия и уведомления в архиве.
PDF схемы и технические материалы платы Olimex Neo6502kbd. В архиве 1 PDF; страниц: 1. Файлы: Neo6502kbd_Rev_A. Автор: OLIMEX Ltd. Аппаратные схемы: CERN-OHL-S 2.0; лицензия и уведомления в архиве.
PDF схемы и технические материалы платы Olimex Neo6502pc. В архиве 2 PDF; страниц: 2. Файлы: Neo6502PC-CPU_Rev_B, Neo6502PC-PWR_Rev_B. Автор: OLIMEX Ltd. Аппаратные схемы: CERN-OHL-S 2.0; лицензия и уведомления в архиве.
PDF схемы и технические материалы платы Olimex RVPC. В архиве 2 PDF; страниц: 2. Файлы: RVPC_Rev_A, RVPC_Rev_B. Автор: OLIMEX Ltd. Аппаратные схемы: CERN-OHL-S 2.0; лицензия и уведомления в архиве.
PDF схемы и технические материалы платы Olimex RP2040pc. В архиве 1 PDF; страниц: 1. Файлы: RP2040pc_Rev_B. Автор: OLIMEX Ltd. Аппаратные схемы: CERN-OHL-S 2.0; лицензия и уведомления в архиве.
PDF схемы и технические материалы платы Olimex RP2350pc. В архиве 1 PDF; страниц: 1. Файлы: RP2350pc_Rev_A. Автор: OLIMEX Ltd. Аппаратные схемы: CERN-OHL-S 2.0; лицензия и уведомления в архиве.
ПО для управления дисплеем USB TYPE C Smart Display 3.5'' Много ревизий этих дисплеев у Китайцев, конкретно к этой только это ПО подошло. На сайте производителя ссылка уже не работает.
PDF схемы смартфона Purism Librem 5: основная плата и плата USB-C для ревизий Evergreen, Dogwood, Chestnut и Birch. В комплекте 8 PDF, 88 страниц. На основной плате i.MX8M Quad; схемы питания, памяти, дисплея, аудио и внешних интерфейсов. Автор: Purism SPC; GNU GPLv3+, лицензия и уведомления в архиве.
Python-скрипт (без внешних зависимостей) для чтения заголовка SDL-файлов прошивки Humax 5-го поколения (BCM7358: HTR-1000S, HDR-1000S, IRHD-1000S и т.д.) и проверки CRC-16/ARC. Показывает все поля заголовка, параметры RSA-подписи (sig_sysid/sysver), и проверяет целостность файла. Полезно для диагностики перед прошивкой устройства.
Официальная документация Framework Computer Inc для материнской платы Framework Desktop на AMD Ryzen AI Max (Strix Halo). В архиве: PDF схемы интерфейсов платы и её механического чертежа, 3D CAD платы, корпуса, деталей охлаждения и панелей. Блок-схема включает APU AMD FP11 Strix Point Halo, распаянную память LPDDR5x, SSD M.2, сетевой контроллер Realtek RTL8126, аудиокодек ALC295, EC Nuvoton и внешние разъёмы. Полной принципиальной схемы материнской платы нет. Источник: https://github.com/FrameworkComputer/Framework-Desktop Автор: Framework Computer Inc. Лицензия CC BY 4.0: https://creativecommons.org/licenses/by/4.0/ Снимок официального репозитория от 03.10.2026, commit 75ee2c4395f34d5d98c56f81f4930fe44aed41d0. Оригинальные файлы не изменены; добавлен SOURCE-AND-LICENSE.txt.
D-Link DWL-2100AP — это устаревшая беспроводная точка доступа стандарта 802.11g, работающая на частоте 2.4 ГГц со скоростью до 54 Мбит/с (и до 108 Мбит/с в режиме Turbo) Набор файлов для восстановления прошивки по TFTP.
Service Manual Digital HD Video Camera Recorder SONY DCR-SX73E, DCR-SX-83, DCR-SX83E, HDR-CX110, HDR-CX115, HDR-CX116, HDR-CX150, HDR-CX155, HDR-CX170 Ver. 1.0 & Ver. 1.2 Level 2, Ver. 1.0 Level 3
